P402i / P4000
Compact solution for secure distributed issuance of ePassports
Desktop ePassport printing and encoding
Designed to fit in any office environment, the Matica P402i (P4000) is a four color, secure desktop inkjet printer and encoder for machine readable ePassport booklets. Its state-of-the-art print engine can be combined with a RFID ICAO 9303 compliant chip reader/encoder and a high definition digital camera to provide governments and administrations with a leading desktop ePassport issuance solution.
Compact and easy to use, it has an advanced print engine architecture, specifically developed to ensure high performance, reliability and production efficiency.
It is available in two different configurations (pigmented ink and dyes). It uses a four color (CMYK) cartridge high speed thermal inkjet print engine, able to operate in two modes: text and photo. This speeds up the printing process whilst ensuring a high quality printed photograph.
Its large cartridge capacity enables the issuance of up to 8,000 booklets and prevents downtime during operation. Each page can be individually printed or can be personalized in pairs. Its quiet operation makes it the ideal solution for passport booklet issuance in any office environment. The graphical monochrome LCD user interface enables easy, user-friendly operation.
Key strengths
- Compact desktop design
- 4800 x 1200dpi resolution per color
- ICAO 9303 compliant
- Reliable and easy-to-use
Ideal for
- ePassport issuance
- Travel visas
- Emergency passport issuance
Optional upgrades
- RFID reader/encoder
- High definition digital camera system
Data encoding and data verification
Encoding and data verification options enable RFID ICAO 9303 compliant chip encoding and chip reading for data verification of ePassports. Visual control is performed via data capture through its high definition digital camera to facilitate data consistency check and data verification. Each booklet is automatically verified by the application before final human visual validation.
Product features
Technical specifications
Printing
Method
4 Color thermal inkjet printing
Dye or pigment ink option
Mode
Text and photo mode aimed at
speeding up the printing process
Resolution
Black: 1200 x 1200 dpi
Color: 4800 x 1200 dpi
Print speed
Standard mode: <9s per booklet
High quality mode: <26s per booklet
Print and encoding speed
Up to 120 booklets per hour (sequential data page and chip personalization)
Booklet
ICAO9303 compliant booklets
Booklet page to remain between
124.8mm to 125.2mm
Up to 96 pages
Inks
Color
Pigmented or dye ink: C, M, Y
(1 cartridge per color)
Black
Pigmented ink: K
Cartridge capacity inks:
C, M, Y: 26ml
K: 78.4ml
One set of C, M, Y, K ink supplied with the printer
Connectivity
Interface
Single connection, USB 2.0 B-type
Internal USB Hub (all slots allocated)
USB cable, 1.8 meter length supplied
Platform
Printer dimensions (H x W x D)
26.5cm x 51.5cm x 52cm
(10.43” x 20.26” x 20.47”)
Weight
16 kg
35.27 Lbs
Options
ICAO 9303 compliant RFID reader/writer
High definition digital camera
Consumables
| Ink | Color | Fill level | Part No |
|---|---|---|---|
| Pigment ink | Cyan | 26ml | PR23013800 |
| Pigment ink | Magenta | 26ml | PR23013801 |
| Pigment ink | Yellow | 26ml | PR23013802 |
| Pigment ink | Black | 78ml | PR23013803 |
| Dye ink | Cyan | 26ml | PR23013900 |
| Dye ink | Magenta | 26ml | PR23013901 |
| Dye ink | Yellow | 26ml | PR23013902 |
- Page-2 printing depends on chip characteristics and chip management application
- Sequential data page and chip personalization ICAO page 2 printing time: approx. 6.5 sec. (printing only without booklet handling)
- Sample may be requested by the production team to adjust the device according to the booklet characteristics (subject to a number of units)
